Rev Neurol Neurocir Psiquiat 2023; 51 (1)

Somatosensory evoked potentials, electroencephalogram and postanoxic coma: usefulness in neurological prognosis

Arciniegas-Villanueva AV, Fernández-Díaz EM, Mansilla-Lozano D, González-García E, Sancho-Pelluz FJ, Segura T

Language: Spanish
References: 35
Page: 4-12
PDF size: 304.76 Kb.


ABSTRACT

Introduction: after a postanoxic coma, the challenge for health professionals is to assess early the medium and long-term neurological prognosis. Despite improved prehospital care and measures focused on neuroprotection, postanoxic encephalopathy remains one of the main complications. The use of neurophysiological techniques such as short- and long-latency evoked potentials N20-N70 together with the electroencephalogram can be multimodal techniques that add and increase sensitivity and specificity in these patients. Objective: to define the relationship between short- and medium-latency N20-N70 somatosensory evoked potentials and electroencephalographic findings with mid- to long-term neurological prognosis in post-anoxic coma following cardiorespiratory arrest. Material and methods: retrospective cohort study conducted in patients admitted to the critical care units of our center with a diagnosis of post-anoxic coma. Scope Intensive Care and Resuscitation Unit of the Hospital General Universitario de Albacete. Participants 60 adult patients consecutively included after suffering cardiorespiratory arrest and consequently post-anoxic coma. Main variables of interest: somatosensory evoked potentials (presence or absence N20 and N70). Electroencephalogram (favorable and unfavorable findings). Assessment of functional prognosis using the modified Glasgow coma scale 6-12 months later. Results: bilateral absence of N20 has 100% specificity for ominous short-term prognosis. The presence of N70 has a specificity of 84% for good medium-long term prognosis and its absence shows a sensitivity of 92.7% for poor prognosis. Certain electroencephalographic findings are indicators of poor short-, medium- and long-term prognosis (specificity 100%, sensitivity 56%) while favorable findings were related to adequate recovery. Conclusions: the presence and absence of N20-N70 short- and long-latency somatosensory evoked potentials and electroencephalographic findings are related to the prediction of the neurological prognosis of patients after postanoxic coma. Our work especially highlights the usefulness of N70 as a prognostic factor after postanoxic coma.


REFERENCES

  1. Taccone FS, Cronberg T, Friberg H, Greer D, Horn J, Oddo M et al. How to assess prognosis after cardiac arrest and therapeutic hypothermia. Crit Care Lond Engl. 2014; 18 (1): 202.

  2. Sandroni C, D'Arrigo S, Nolan JP. Prognostication after cardiac arrest. Crit Care Lond Engl. 2018; 22 (1): 150.

  3. Daubin C, Guillotin D, Etard O, Gaillard C, du Cheyron D, Ramakers M et al. A clinical and EEG scoring system that predicts early cortical response (N20) to somatosensory evoked potentials and outcome after cardiac arrest. BMC Cardiovasc Disord. 2008; 8 (1): 35.

  4. Wijdicks EFM, Hijdra A, Young GB, Bassetti CL, Wiebe S. Practice parameter: prediction of outcome in comatose survivors after cardiopulmonary resuscitation (an evidence-based review) report of the quality standards subcommittee of the American Academy of Neurology. Neurology. 2006; 67 (2): 203-210.

  5. Giacino JT, Katz DI, Schiff ND, Whyte J, Ashman EJ, Ashwal S et al. Practice guideline update recommendations summary: Disorders of consciousness: Report of the Guideline Development, Dissemination, and Implementation Subcommittee of the American Academy of Neurology; the American Congress of Rehabilitation Medicine; and the National Institute on Disability, Independent Living, and Rehabilitation Research. Neurology. 2018; 91 (10): 450-460.

  6. André-Obadia N, Zyss J, Gavaret M, Lefaucheur J-P, Azabou E, Boulogne S et al. Recommendations for the use of electroencephalography and evoked potentials in comatose patients. Neurophysiol Clin. 2018; 48 (3): 143-169.

  7. Oddo M, Rossetti AO. Early multimodal outcome prediction after cardiac arrest in patients treated with hypothermia. Crit Care Med. 2014; 42 (6): 1340-1347.

  8. Ferré A, Lainez E, Moreno I. Utilización de potenciales evocados en unidades de cuidados intensivos. Neurol Publ Of Soc Esp Neurol. 2009; 24 (3): 181-193.

  9. Scarpino M, Carrai R, Lolli F, Lanzo G, Spalletti M, Valzania F et al. Neurophysiology for predicting good and poor neurological outcome at 12 and 72 h after cardiac arrest: The ProNeCA multicentre prospective study. Resuscitation. 2020; 147: 95-103.

  10. Zandbergen EGJ, Koelman JHTM, de Haan RJ, Hijdra A, PROPAC-Study Group. SSEPs and prognosis in postanoxic coma: only short or also long latency responses? Neurology. 2006; 67 (4): 583-586.

  11. Oddo M, Rossetti AO. Predicting neurological outcome after cardiac arrest. Curr Opin Crit Care. 2011; 17 (3): 254-259.

  12. Robinson LR, Micklesen PJ, Tirschwell DL, Lew HL. Predictive value of somatosensory evoked potentials for awakening from coma. Crit Care Med. 2003; 31 (3): 960-967.

  13. Barba C, Frot M, Valeriani M, Tonali P, Mauguiere F. Distinct fronto-central N60 and supra-sylvian N70 middle-latency components of the median nerve SEPs as assessed by scalp topographic analysis, dipolar source modelling and depth recordings. Clin Neurophysiol. 2002; 113 (7): 981-992.

  14. Madl C, Kramer L, Domanovits H, Woolard RH, Gervais H, Gendo A et al. Improved outcome prediction in unconscious cardiac arrest survivors with sensory evoked potentials compared with clinical assessment. Crit Care Med. 2000; 28 (3): 721-726.

  15. Rothstein TL. The role of evoked potentials in anoxic-ischemic coma and severe brain trauma. J Clin Neurophysiol. 2000; 17 (5): 486-497.

  16. Madl C. Prognostic evaluation of brain dysfunction after cardiopulmonary resuscitation. Intensivmed. 1994; 31: 21-25.

  17. Pardal-Fernández JM, Arciniegas A, Mansilla-López D, Sánchez-Iniesta R, Gutiérrez-Rubio JM. A new case of the absence of N20 at early cerebral anoxia-ischemia evaluation by somatosensory evoked potentials. Med Intensiva. 2014; 38 (3): 194-195.

  18. Sandroni C, D'Arrigo S, Cacciola S, Hoedemaekers CWE, Kamps MJA, Oddo M et al. Prediction of poor neurological outcome in comatose survivors of cardiac arrest: a systematic review. Intensive Care Med. 2020; 46 (10): 1803-1851.

  19. Nolan JP, Sandroni C, Bottiger BW, Cariou A, Cronberg T, Friberg H et al. European Resuscitation Council and European Society of Intensive Care Medicine Guidelines 2021: Post-resuscitation care. Resuscitation. 2021; 161: 220-269.

  20. Comanducci A, Boly M, Claassen J, De Lucia M, Gibson RM, Juan E et al. Clinical and advanced neurophysiology in the prognostic and diagnostic evaluation of disorders of consciousness: review of an IFCN-endorsed expert group. Clin Neurophysiol. 2020; 131 (11): 2736-2765.

  21. Rossetti AO, Oddo M, Logroscino G, Kaplan PW. Prognostication after cardiac arrest and hypothermia: a prospective study. Ann Neurol. 2010; 67 (3): 301-307.

  22. Guérit J-M. Evoked potentials in severe brain injury. Prog Brain Res. 2005; 150: 415-426.

  23. Koenig MA, Kaplan PW. Clinical applications for EPs in the ICU. J Clin Neurophysiol. 2015; 32 (6): 472-480.

  24. Young GB. The EEG in coma. J Clin Neurophysiol. 2000; 17 (5): 473.

  25. Lachance B, Wang Z, Badjatia N, Jia X. Somatosensory evoked potentials and neuroprognostication after cardiac arrest. Neurocrit Care. 2020; 32 (3): 847-857.

  26. Stevens RD, Sutter R. Prognosis in severe brain injury. Crit Care Med. 2013; 41 (4): 1104-1123.

  27. Wilson JT, Pettigrew LE, Teasdale GM. Structured interviews for the Glasgow Outcome Scale and the extended Glasgow Outcome Scale: guidelines for their use. J Neurotrauma. 1998; 15 (8): 573-585.

  28. Lew HL, Dikmen S, Slimp J, Temkin N, Lee EH, Newell D et al. Use of somatosensory-evoked potentials and cognitive event-related potentials in predicting outcomes of patients with severe traumatic brain injury. Am J Phys Med Rehabil. 2003; 82 (1): 53-61.

  29. Lori S, Bertini G, Molesti E, Gualandi D, Gabbanini S, Bastianelli ME et al. The prognostic role of evoked potentials in neonatal hypoxic-ischemic insult. J Matern-Fetal Neonatal Med. 2011; 24 Suppl 1: 69-71.

  30. Robinson LR, Micklesen PJ. Somatosensory evoked potentials in coma prognosis. Phys Med Rehabil Clin N Am. 2004; 15 (1): 43-61.

  31. Rothstein TL, Thomas EM, Sumi SM. Predicting outcome in hypoxic-ischemic coma. A prospective clinical and electrophysiologic study. Electroencephalogr Clin Neurophysiol. 1991; 79 (2): 101-107.

  32. Barbella G, Novy J, Marques-Vidal P, Oddo M, Rossetti AO. Added value of somato-sensory evoked potentials amplitude for prognostication after cardiac arrest. Resuscitation. 2020; 149: 17-23.

  33. Sherman AL, Tirschwell DL, Micklesen PJ, Longstreth WT, Robinson LR. Somatosensory potentials, CSF creatine kinase BB activity, and awakening after cardiac arrest. Neurology. 2000; 54 (4): 889-894.

  34. Rossetti AO, Carrera E, Oddo M. Early EEG correlates of neuronal injury after brain anoxia. Neurology. 2012; 78 (11): 796-802.

  35. Zandbergen EG, de Haan RJ, Stoutenbeek CP, Koelman JH, Hijdra A. Systematic review of early prediction of poor outcome in anoxic-ischaemic coma. Lancet Lond Engl. 1998; 352 (9143): 1808-1812.
