Rev Mex Anest 2021; 44 (2)

Airway ultrasound: in search of the cricothyoid membrane

Fernández-Vaquero M?, Carrillo-Esper R

Language: Spanish
References: 12
Page: 116-122
PDF size: 609.16 Kb.


ABSTRACT

Ultrasonography is an active part of the clinical tools that we have in our arsenal for the evaluation of patients, and in the management of the airway, it can allow us to locate and mark the cricothyroid membrane prior to the management of a patient with a possible Difficult Airway. In trained hands allows the anatomy to be identified so that a cricothyroidotomy can be performed quickly and accurately in just 24.3 seconds. In this article, we show a rapid and visual systematic ultrasound localization of the cricothyroid membrane with an estimated time less than one minute. A linear high-frequency probe (5-14 MHz) should be used for exploration, as it is probably the most suitable for evaluating surface structures (within 0-5 cm below the skin surface). The positioning of the operator and the ultrasound scanner will depend on the patient's position, so in seated patients the operator is placed behind him and the ultrasound scanner in front of both, and in patients in a supine position, the operator is placed at the bedside of the patient and the ultrasound at the level of the right elbow.


REFERENCES

  1. Caplan RA, Posner KL, Ward RJ, Cheney FW. Adverse respiratory events in anesthesia: a closed claims analysis. Anesthesiology. 1990;72:828-833.

  2. Metzner J, Posner KL, Lam MS, Domino KB. Closed claims' analysis. Best Pract Res Clin Anaesthesiol. 2011;25(2):263-276. Available from: http://dx.doi.org/10.1016/j.bpa.2011.02.007.

  3. Cheney FW, Posner KL, Lee LA, Caplan RA, Domino KB. Trends in anesthesia-related death and brain damage: a closed claims analysis. Anesthesiology. 2006;105:1081-1086.

  4. Peterson GN, Domino KB, Caplan RA, Posner KL, Lee LA, Cheney FW. Management of the difficult airway: a closed claims analysis. Anesthesiology. 2005;103(1):33-39.

  5. Elliott DSJ, Baker PA, Scott MR, Birch CW, Thompson JMD. Accuracy of surface landmark identification for cannula cricothyroidotomy. Anaesthesia. 2010;65:889-894.

  6. Kristensen MS, Teoh WH, Graumann O, Laursen CB. Ultrasonography for clinical decision-making and intervention in airway management: from the mouth to the lungs and pleurae. Vol. 5, Insights into Imaging. 2014. p. 253-279.

  7. Torres-Gallardo B, Bergé R, Sala-Blanch X, Prats-Galino A. Anatomical description of laryngeal ultrasound windows. Rev Esp Anestesiol Reanim. 2015;62:297-298.

  8. Chalumeau-Lemoine L, Baudel JL, Das V, Arrivé L, Noblinski B, Guidet B, et al. Results of short-term training of naive physicians in focused general ultrasonography in an intensive-care unit. Intensive Care Med. 2009;35:1767-1771.

  9. Nicholls SE, Sweeney TW, Ferre RM, Strout TD. Descripción anatómica de las ventanas laríngeas ecográficas. Am J Emerg Med. 2008;26:852-856.

  10. Osman A, Sum KM. Role of upper airway ultrasound in airway management. J Intensive Care. 2016; 4: 52.

  11. Alerhand S. Ultrasound for identifying the cricothyroid membrane prior to the anticipated difficult airway. Am J Emerg Med. 2018;36:2078-2084.

  12. Kristensen MS, Teoh WH, Rudolph SS. Ultrasonographic identification of the cricothyroid membrane: best evidence, techniques, and clinical impact. Br J Anaesth. 2016;117:i39-i48. Available from: http://dx.doi.org/10.1093/bja/aew176.
