Trap-door thoracotomy as an ideal access route for internal cardiac massage and repair of subclavian vessels
Full text
10.35366/111548
Language: English
References: 18
Page: 59-65
PDF size: 310.87 Kb.
ABSTRACT
Introduction: subclavian vessel injuries remain rare and highly lethal. Patients with these types of injuries can present with neck and upper chest hematoma, hemorrhage, and signs of upper limb ischemia. Trap-door thoracotomy allows wide exposure of the thoracic cavity and base of the neck, providing rapid access to the heart, subclavian vessels, pulmonary ileus, and other anterior mediastinal structures. Objective: to describe the trap-door thoracotomy as the ideal approach for internal cardiac massage and subclavian vascular repair in hemodynamically unstable patients. Cases presentation: two patients with severe subclavian artery injuries are presented. They underwent emergency surgery using a trap-door thoracotomy, where bypass was performed from the ascending aorta to the left axillary artery with a polytetrafluoroethylene prosthesis in the first case and bypass from the left carotid artery to the left subclavian artery with an inverted saphenous vein in the second patient. Conclusion: the trap-door thoracotomy allows optimal access to the subclavian vessels and the heart if cardiopulmonary resuscitation is needed in critically ill patients.INTRODUCTION
Subclavian vein (SV) and subclavian artery (SA) injuries are relatively uncommon because they are vessels of short extension protected by osteoarticular structures of the thoracic cavity. These injuries represent 1 to 9% of all vascular trauma cases, with 90% being caused by a penetrating mechanism secondary to stab and firearm injuries, and only 5% originate from the blunt trauma mechanism.1-3
A subclavian vascular injury is suspected when trauma to the upper third of the chest wall located in the clavicle or supraclavicular fossa is associated with a decreased or absent pulse in the upper limb of the same name, hemorrhage, local hematoma, shock, and first rib fracture.1 Concomitant involvement of the subclavian vein and subclavian artery occurs in 20% of cases, with brachial plexus injury occurring in a third of these traumas, increasing mortality from 10 to 35%.4
The unilateral anterior cervico-sterno-thoracotomy or "Trap-door" incision was first described in 1979 by Masaoka et al. It is performed in a supine position with the neck extended; it includes a high median sternotomy (MS) that communicates with an anterior incision at the level of the fourth intercostal space and another transverse incision at the base of the neck, dividing the infrahyoid muscles. The anterior flap is retracted as an open book to expose structures such as the pulmonary apex and hilum, subclavian vessels and brachial plexus.5 It also offers access to other structures, such as the supra-aortic arteries, for proximal vascular control and heart if a more effective cardiopulmonary resuscitation is required to perform direct cardiac massage in patients with hemodynamic instability.
CASES PRESENTATION
CASE 1
A 19-year-old male was brought by relatives with a penetrating injury caused by a gunshot to the left shoulder. On physical examination, the patient was hypotensive (85/55 mmHg), with a giant hematoma in the shoulder and left hemithorax. The neurological examination revealed spastic paraplegia of the lower limbs, absence of left axillary, brachial, and radial pulses, homonymous hand coldness and cyanosis.
Chest X-ray revealed a bullet in the upper left hemithorax at the level of the fourth cervical vertebrae. Four units of red blood cells and two plasma were requested, and two grams of intravenous (IV) cefazolin were given. Emergency surgery is then indicated.
The patient suffered cardiac arrest during anesthetic induction. The left anterior thoracotomy was done through the fourth intercostal space. The ventricles appeared to be fluctuating on palpation when the pericardium was opened (Figure 1A), and the cardiac monitor demonstrated fine ventricular fibrillation. Manual cardiac massage and external electrical defibrillation with 250 Joules were performed until hemodynamic stabilization was achieved.
A large hematoma displacing the left lung is found, and the trap-door incision is completed with dislocation of the left sternoclavicular joint (Figure 1B), exposing the subclavian vessels and anterior mediastinum. After hematoma evacuation, a neurovascular injury with loss of the subclavian segments of the SV, SA, and brachial plexus was found. In addition, an aortic hematoma was found at the origin of the subclavian artery, making it impossible to perform the anastomosis to the descending aorta or left carotid (LC) artery.
The bleeding source was controlled with ligation of subclavian vessels and dissection of the left axillary artery (Figure 1C). Partial clamping and bypass of the ascending aorta to the left axillary artery with a polytetrafluoroethylene (PTFE) prosthesis were performed (Figure 2A), (Figure 2B) and arterial flow restoration of the left upper limb was achieved. Hemostasis was checked, and the chest wall was closed, showing how the trap-door thoracotomy was left. The thorax outlet of the PTFE prosthesis is also observed (Figure 2C). Five minutes after the closure of the thoracic cavity, the patient presented ventricular fibrillation that resolved with defibrillation with 300 Joules.
The patient was transferred to the recovery room with inotropic support with a mean arterial pressure above 60 mmHg. Twelve hours after the surgical procedure, about 500 mL of blood was drained from the chest tube. Prolonged prothrombin time (PT) and activated partial thromboplastin time (aPTT) were found in coagulation tests. There was no evidence of residual hemothorax on chest X-ray images. Transfusion of two red blood cells and two plasma units were requested, and 500 mg of IV tranexamic acid every eight hours was indicated. There was a hemodynamic improvement within 48 hours postoperatively, but extreme bradycardia persisted, and the possibility of referring the patient to a tertiary center for pacemaker placement was assessed. Epinephrine and atropine were added, but the heart rate did not improve. The patient died 72 hours after the surgical procedure.
CASE 2
An 18-year-old male was brought to the emergency department with blunt chest trauma and a left humerus fracture due to a motorcycle accident. On physical examination, the patient was hypotensive (90/57 mmHg), with a giant hematoma in the shoulder and left hemithorax. Left upper limb deformity due to humerus fracture was observed. There were signs of limb ischemia with absence of axillary and radial pulses.
Chest X-ray revealed a left humerus fracture, and a chest tomography showed a giant hematoma in the upper left hemithorax. Three red blood cells and two plasma units were requested, and two grams of IV cefazolin were given.
Emergency surgery was decided due to the patient's hemodynamic instability. General endotracheal anesthesia was indicated, and inotropic support with norepinephrine was started due to severe hypotension. Left anterior thoracotomy was done through the fourth intercostal space, where the patient presented bradycardia and asystole, for which it was necessary to perform cardiac massage. After hemodynamic stabilization, a giant hematoma displacing the left lung is found. Vascular control of the mammary artery was performed, and the trap-door thoracotomy was completed with the dislocation of the left external clavicular joint to expose the subclavian vessels and the anterior mediastinum (Figure 3A).
A five centimeter SA laceration with lesions of the SV and brachial plexus were found.
Ligation of various bleeding sources and hematoma drainage was done. The intrathoracic LC artery was dissected, and a vascular bypass was performed from this artery to the distal end of the SA with the left greater saphenous vein (Figure 3B). A spontaneous arterial pulse and an arterial saturation greater than 95% of the upper left limb were observed. The SV was repaired with a 6/0 polypropylene suture.
Hemostasis was checked, and a chest tube was placed in the extrapleural space. The thoracotomy was closed with wires in the sternum and pericostal sutures on the thoracotomy (Figure 3C and D). A fasciotomy was performed due to humerus fracture in the proximal third of the arm.
The patient was transferred to the recovery room with inotropic support of norepinephrine 8 mL/h, 1 gram of ceftriaxone IV every 8 hours and 500 mg of amikacin IV every 12 hours. The chest tube output was low. However, the X-ray showed moderate effusion, so repositioning a new chest tube in the intrapleural space was required (Figure 4A), which drained 700 mL of hematic fluid. The extrapleural chest tube was removed 28 hours later (Figure 4B).
Endotracheal extubation and intrapleural chest tube removal were performed within 72 hours postoperatively. The patient remained in the intensive care unit for 5 days and was then transferred to the ward, where was assessed by the neurosurgery and traumatology team for brachial plexus injury and humerus fracture, respectively. The patient was discharged from the hospital 15 days later. Since then, the patient has been in constant evaluation for 2 years, with a chest CT angiography that demonstrated graft patency (Figure 4C and D), although the brachial plexus injury has caused immobility and atrophy of the left shoulder and upper limb.
DISCUSSION
The prognosis of trauma to the subclavian vessels depends on variables such as type of injury, affected vessel, degree of hemorrhage, and the time between injury and specific treatment. Demetriades et al. reported that 44% of his patients had isolated SV lesions, 39% had SA lesions, and 17% had combined artery and vein injuries.6 Similar results were obtained by Lin et al, where the concomitant arterial and venous injuries were identified in 24 of the 54 patients of their study.4 In the present study, the severity of the clinical picture indicated emergency surgical treatment in both patients.
Mortality from isolated SV lesions can be up to 80%, significantly higher than in the presence of arterial or combined subclavian injury.6 Another study reported death in half of the patients with isolated SV lesions.3 This could be associated with embolus or continuous venous bleeding. Some authors state that subclavian vessel injuries can sometimes be suspected clinically. Physical examination findings in SA lesions include the absence of pulses in upper extremities, brachial plexus palsy, audible murmur, supraclavicular hematoma, first rib fracture, and active bleeding.7,8
Primary identification of subclavian vascular injuries is often made intraoperatively due to the patient's hemodynamic instability, which precludes the possibility of obtaining imaging studies to corroborate the diagnosis. The patients in our report presented with giant hematomas of the upper left hemithorax, with a humerus fracture and a gunshot wound to the cervical spine, respectively. Computed tomography angiography provides the best diagnostic information to identify subclavian vascular injuries.9
The choice of surgical approach and incision type is one of the essential points to maintaining the patient's hemostasis; this depends on the injured side and the location of arterial and venous interruption. For some authors, the standard approach for left-sided trauma is anterolateral thoracotomy with a posterior supraclavicular or infraclavicular incision, while right-sided injuries are generally treated with an MS with supraclavicular extension.10 MS has also been successfully used to expose the left subclavian artery, which provides a wide operative field, and allows rapid vascular control.9 In our cases, the classic "Trap-door" thoracotomy surgical technique was used, which has been associated with a higher incidence of severe postoperative bleeding and respiratory complications.3,11
The unilateral anterior cervical-sterno-thoracotomy incision or "Trap-door" incision was first described as a route of exposure for Pancoast tumors of the superior sulcus.5 Since then, it has been used by thoracic surgeons as an approach to lung and upper mediastinum tumors. It also allows a better view of large vessels of the mediastinum and neck.12 In our patients, this approach was considered an ideal technique, with the minor modification of performing sternoclavicular dislocation due to its rapid access to the subclavian vessels. It was also possible to expose the heart to perform internal cardiac massage and, at the same time, perform proximal vascular control to avoid profuse bleeding.
The lack of exposure of the medial and distal subclavian vessels is a disadvantage of this approach. Supraclavicular or infraclavicular incisions expose the subclavian vessels but require the surgeon to perform external cardiac massage with the impossibility of proximal vascular control if profuse bleeding is presented. The trap-door technique should be considered an ideal approach to perform an effective cardiac massage to achieve cardiopulmonary resuscitation and control of SA lesions.
The endovascular approach as a treatment option for penetrating and blunt injuries of the subclavian vessels is relatively new. It includes polytetrafluoroethylene (PTFE)-coated endoprostheses with an expandable or self-expandable balloon.13,14 This approach has been commonly used for pseudoaneurysms and left SA lesions due to its thoracic location compared to the right SA, which is extrathoracic.2
Most subclavian vascular injuries require significant open intervention for proper management.15 Posner concluded that open anatomic repair is the most desirable option to prevent subclavian steal syndrome, claudication, or ischemia leading to limb amputation.16
Long-term morbidity is closely related to the presence of associated brachial plexus injuries.17 In the study conducted by Graham, brachial plexus injuries were observed in 34% of the patients.18 Unfortunately, cases of complete brachial plexus transection and secondary nerve repair may only return minimal functional improvement and leave the patient with permanent functional disability. In our study, brachial plexus injury was present in both patients.
CONCLUSION
The trap-door thoracotomy allows optimal access to structures like the mediastinum, hilum and lung parenchyma. Its wide exposure provides proximal and distal vascular control of the great vessels, an essential requirement to achieve adequate repair of such structures. Its cervical extension offers exposure of the proximal and medial course of the subclavian vessels below the clavicle. It also helps to expose the heart and pericardium to perform an effective internal cardiac massage in critically ill patients.
